Detailed Product Description

Railway Bearing 229750C
1.Self-aligning,
2.Heavy Loads
3.Vibrating Applications
4.Best Price

Bearings for modern railway systems must offer excellent durability and high-speed capability with minimal maintenance requirements. Incorporating years of experience and engineering know-how, OEM bearings consistently exceed industry expectations

Bearing Number		Withdrawal Sleeve	Boundary Dimensions (mm)								Load Rating(kN)		Mass (kg) approx.
Cylindrical Bore	Tapered Bore		d	d1	D	B	r(1)	L	L1	D1	Dynamic	Static	Bearing	Bearing and Sleeve
230092C	-	-	99.746	-	180	60.3	3.5	-	-	-	420	605	6.6	-
23220C	23220CK	AHX3220	100	95	180	60.3	2.1	73	77	M110 × 2	420	605	6.6	7.4
23122C	23122CK	AHX3122	110	105	180	56	2	68	72	M120 × 2	385	630	5.8	6.55
231255C	-	-	119.105	-	200	62	2 5	-	-	-	465	720	8	-
23124C	23124CK	AHX3124	120	115	200	62	2	75	79	M130 × 2	465	720	7.95	8.9
23224C	23224CK	AHX3224	120	115	215	76	2.1	90	94	M135 × 2	630	970	12.3	13.6
22324C	22324CK	AHX2324	120	115	260	86	3	105	109	M135 × 2	845	1 130	22.8	24.4
23126C	23126CK	AHX3126	130	125	210	64	2	78	82	M140 × 2	505	825	8.8	9.9
229750C	-	-	130	-	220	73	2.7 5	-	-	-	575	960	11.7	-
23226C	23226CK	AHX3226	130	125	230	80	3	98	102	M145 × 2	700	1 080	14.5	16.1
22326C	22326CK	AHX2326	130	125	280	93	4	115	119	M145 × 2	995	1 350	28.4

more information: pls send a require to us,E-MAIL:bearingbrands@yahoo.com
